CS-Prep® industrial preparative HPLC systems consists of an infusion section, an injection section, a detection section, a distillate collection section, a control and data processing section. It is the first diaphragm pump explosion-proof industrial preparation liquid chromatography system in China, which can achieve balance, sample loading, flushing, elution, automatic collection, online cleaning and other process.
Hanbon, one of the leading HPLC system manufacturers, offers CS-Prep® as part of its advanced line of HPLC systems for sale. This system delivers high precision and reliability, making it ideal for large-scale industrial applications.
High precision and stability;
Key components adopt internationally renowned brands;
The control software is based on the secondary development of imported workstations and meets the requirements of FDA 21CFR Part 11;
Based on the design and implementation process of GAMP 5, provide complete GMP and FDA verification documents and services.
| Model No. | CS-Prep 150/ 200 | CS-Prep 300 | CS-Prep 400-500 | CS-Prep 600 | CS-Prep 800 | CS-Prep 1000/ 1100 | CS-Prep 1200 | CS-Prep 1600 | CS-Prep 2000 |
| Pump max flow(L/h)* | 200 | 293 | 516 | 1200 | 1979/3000 | 3000/ 5000 | 10000 | 10000 | |
System control accuracy | Gradient range: 5%~95%, flow rate error ≤±1% | ||||||||
| Chromatography column | DAC 150/200 | DAC300 | DAC400～500 | DAC600 | DAC800 | DAC 1000/1100 | DAC1200 | DAC 1600 | DAC2000 |
| Weight(kg) | 1100 | 2000 | 2300 | 2500 | 3000 | ||||
| Tube | 1/8"or 1/4" tube | 1/4" tube | 1/2"tube | 3/4" tube | 1" tube | 1" or 1.5" tube | 1.5" tube | 1.5" tube | |
| Material | ASTM A269(SS316L) | ||||||||
| Max work pressure ** | 10MPa | 7MPa | |||||||
| Detector | Single wavelength, double wavelength, or four wavelengths (190-400nm、190-700nm或200-800nm) | ||||||||
| Explosion-proof level | ExdIIBT4 | ||||||||
Note:
The above parameters are for reference only, the actual data is subject to DQ design documents.
**System flow rate is the recommended flow rate configuration, you can select the appropriate system pump according to the user's process.
**Maximum system pressure is the highest pressure the system can be designed, the actual programme is adjusted according to the user's process requirements.
